Fabric properties
Blackout
Polyester acrylic-coated
445 g/m²
0.70 mm
275 cm
280 cm
Features / Technical properties
4-5
Flame retardant
Fabric must be turned
Oeko-Tex
Special colours from 1’000 m
Washing instructions
-1.5%
-0.75%
Iron only on the face (front) side!
Optical and solar coefficients (± 5%, DIN EN 410)
| Colour |
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|
| Colour 1 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 66.2 | As(%) 33.8 | Tuv(%) 0.00 | Fc() 0.50 | gtot() 0.36 |
| Colour 2 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 66.2 | As(%) 33.8 | Tuv(%) 0.00 | Fc() 0.50 | gtot() 0.36 |
| Colour 3 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 66.2 | As(%) 33.8 | Tuv(%) 0.00 | Fc() 0.50 | gtot() 0.36 |
| Colour 4 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 66.2 | As(%) 33.8 | Tuv(%) 0.00 | Fc() 0.50 | gtot() 0.36 |
| Colour 10 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.4 | As(%) 29.6 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 12 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.4 | As(%) 29.6 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 13 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.4 | As(%) 29.6 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 15 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.4 | As(%) 29.6 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 16 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.4 | As(%) 29.6 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 18 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 62.6 | As(%) 37.4 | Tuv(%) 0.00 | Fc() 0.52 | gtot() 0.37 |
| Colour 20 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 62.6 | As(%) 37.4 | Tuv(%) 0.00 | Fc() 0.52 | gtot() 0.37 |
| Colour 21 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 62.6 | As(%) 37.4 | Tuv(%) 0.00 | Fc() 0.52 | gtot() 0.37 |
| Colour 22 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 70.4 | As(%) 29.6 | Tuv(%) 0.00 | Fc() 0.47 | gtot() 0.34 |
| Colour 23 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 66.2 | As(%) 33.8 | Tuv(%) 0.00 | Fc() 0.50 | gtot() 0.36 |
| Colour 24 | Tv(%) 0.0 | Ts(%) 0.0 | Rs(%) 62.6 | As(%) 37.4 | Tuv(%) 0.00 | Fc() 0.52 | gtot() 0.37 |
Fc + gtot: Value calculated with glass: 0.72 / Ug = 1.6 W/m² K, DIN EN 13363-1
Classification of solar shading devices (DIN EN 14501:2021)
| Colour | Glare control | Privacy at night | Sight contact with the outside | Daylight utilisation |
|---|---|---|---|---|
| Colour 1 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 2 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 3 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 4 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 10 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 12 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 13 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 15 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 16 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 18 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 20 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 21 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 22 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 23 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
| Colour 24 | Glare control 4 | Privacy at night 4 | Sight contact with the outside 0 | Daylight utilisation 0 |
0: No effect, 1: Low effect, 2: Medium effect, 3: High effect, 4: Very high effect
Downloads
On request:
Class 1 (UNI 8456)
NFPA 701
IMO
